- Frequency Response,
- Process Mode: Program controlled
- Bypass Mode: 10Hz to 50kHz, +/- 0.5dBu, 0dBu input
- Signal to Noise Ratio: 115dB Process IN
- THD, Process mode: less than 0.025% 20-20kHz
- Bypass mode: less than 0.002% 20-20kHz
- Maximum Output: +23dBu (may vary due to control settings)
- Input Impedance: 14.7K Ohms, balanced 1/4″ stereo phone jack or XLR jack. Pin #2 is the hot or “+” signal.
- Output Impedance: 600 Ohms, balanced 1/4″ stereo phone jack or XLR jack. Pin #2 is the hot or “+” signal.
- Sensitivity: -45dBu for maximum process
- Maximum Process: +12dBu boost at 5kHz, 0dBu input
- Lo Contour: +12dBu adjustment at 50Hz, 0dBu input
Designed and Engineered in USA
Made in China
